System
Main Processor: ARM Cortex A7 Processor
Operating System: Embedded LINUX
Video
Input: 9CH(3840*2160,2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc)
Output: 1 VGA, 1 HDMI
Audio
Input: 1 Port RCA
Output :1 Port RCA(Linear, 1kΩ)
Audio Bit Rate:...
Availability: Low stock: 20 left
Couldn't load pickup availability
Orders are processed within 1–2 business days after your payment is confirmed. If you order on a weekend or holiday, processing begins on the next business day. Most domestic orders are delivered within approximately 1–5 business days after shipment. We ship within the United States only. Shipping costs, if any, are shown at checkout, and some products or orders may qualify for free shipping. Once your order is dispatched, you'll receive a shipping confirmation email with your tracking number. Delivery dates are estimates and are not guaranteed.
We accept return requests within 180 days after delivery. Items should generally be in the same condition as received, unworn and unused where applicable, with original tags and packaging. Approved refunds go to your original payment method, generally within 10 business days after approval. For damaged, defective, or incorrect items, contact us as soon as possible. Please contact support@merchsection.com before returning an item.
Products are covered by the manufacturer's warranty where the manufacturer states one — check the product description for warranty details. Every order is also covered by our 180-day return promise: if an item arrives damaged, defective, or incorrect, contact us at support@merchsection.com and we'll make it right.
System
Main Processor: ARM Cortex A7 Processor
Operating System: Embedded LINUX
Video
Input: 9CH(3840*2160,2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc)
Output: 1 VGA, 1 HDMI
Audio
Input: 1 Port RCA
Output :1 Port RCA(Linear, 1kΩ)
Audio Bit Rate: 64kbps
Audio Compression standard: G711u, G711a, ADPCM_DVI4
Intercom: support (two-way)
Alarm
Sensor Input : NO
Output : NO
Motion Detection: 9 Channel, MD Zones: 396 (22 × 18)
Trigger Events : Recording, Email, FTP, Snapshot, Buzzer and Screen Tips
Display
HD Output1: 1024x768/60Hz，1280x720/60Hz，1280x1024/60Hz，1920x1080/60Hz，4K(3840x2160)/30Hz
HD Output2 : /
VGA Resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Display Split : 9CHxD1/8CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k
Digital Zoom: YES
OSD: Camera Title, Time, Recording, Motion Detection, Event Alarm
Recording
Video Compression: H265/H264/H265+/H264+
Resolution :
4k(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),
1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480)
Record Rate :
PAL :4K@8x25fps,5MP@9×25fp,4MP@9x25fp,3MP@9×25fp,1080P@9×25fp, 960P@9×25fp,720P@9×25fp, D1@9×25fp
NTSC: 4K@8x30fps,5MP@9×30fp,4MP@9×30fp,3MP@9×30fp,1080P@9×30fp, 960P@9×30fp, 720P@9×30fp,
D1@9×30fp
Record Mode : Manual\Timer\Motion Detection\Smart Event
Playback & Backup
Local Sync Playback : 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps,
4CH 960P@30fps, 4CH 720P@30fps,9CH D1@30fps
Decode Capability : 4CH 1080P(1920x1080)@30fps
Remote Sync Playback : YES
Search Mode : ALL, Channel, Manual, Time, Date, Motion Detection,Event Alarm,Tag search
Playback Functions : Play, Pause, Stop, Rewind, Fast play, Slow Play, Full Screen, Frame Play ,Frame Rewind, Digital Zoom,tag,clip
Backup Mode : USB Device/Network
Network
Interface : 1 x RJ45 (10M/100M Adaptive Ethernet Interface)
Incoming Bandwidth : 80MB
Network Functions : TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE
Onvif Version: onvif S,onvif T
Web Browser: Edge,IE8-11, Google Chrome , Firefox ,Safari
CMS Software: Support Windows 7/ Windows 8/Windows 10/MAC OS
Cloud Support: Yes
Smart Phone: iPhone, iPad, Android, Android Pad
POE: /
WIFI UI: /
Storage
Interface Type: 1 SATA Hard Disk Interface (3.5" SATA)
Capacity: Up to 8TB capacity
eSATA: /
General
Language:
Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,
German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese,Janpanese
USB Interface: 2 USB 2.0 Interfaces
RS485: /
Power Supply: DC12V 2A
Working Environment: -10~55℃/10~90%
Dimension(W×D×H): 260*215*43(mm)
Weight: 2kg(without HDD)
